Description
how the PTM7950 thermal pad works ?
At room temperature, thermal conductive phase change materials remain solid and cannot discharge air from the interface (Picture 1)
As the temperature increases, the phase change thermal conductive material becomes softer and the air at the interface begins to be discharged, and the temperature also begins to decrease (Picture 2)
When the phase change thermal conductive material reaches the phase change temperature(45°C), it becomes liquid and can greatly wet the interface, discharge the air inside the interface, reduce the interface thermal resistance, and transfer heat as much as possible; When the device is in a non working state, the phase change thermal conductive material becomes solid again, but maintains 100% complete wetting of the interface (Picture 3)
Easy to use, Noted: thermal pad is gray, the protective film may be clear or blue, so it is normal if looks gray or blue
Widely Application
8.5W/mK high heat dissipation performance.Effectively improve the performance of notebook computers, cpu, ssd, gpu game consoles or other integrated circuit chips.
- Material: it is small in size and lightweight, making it convenient to carry and store when not in use. Made of high quality silicone, the heat conductive pad is soft and durable, with smooth surface and exquisite workmanship.
- Advanced technology: ultra-high thermal conductivity phase-change material (PCM), available in phase-change pad and sheet form, aims to reduce interface thermal resistance, pass reliability tests, and maintain excellent performance.
- Reliable: it is an exclusive material that offers excellent reliability (through cooking at 150 ℃ for 1000 hours, T/C-B for 1000 cycles) and maintains a low thermal impedance, making the PTM7950 series the best choice for high-performance integrated circuit equipment.
- Ease of use: it is recommended to use the pressure and temperature of the clamp to achieve a minimal adhesive line thickness for thermal interface materials, generally less than 0.038 mm for optimal performance.
- Product Usage: The heat dissipation mat is specially designed for processors, GPUs, graphics cards, power supplies, computer hosts, laptops, and all heat dissipation modules you need. Use it to heat your laptop or computer and prevent overheating.
- PTM7950 is a highly thermally conductive Phase Change Material (PCM) that lasts longer and is more effective than tradiational thermal paste.
- Size 40x80x0.25mm, Phase change, Thermal Conductivity: 8W/m.K,
- PTM7950 is a proprietary material that provides superior reliability and maintains low thermal impedance (<0.06K·cm²/W @ 30Psi), making the PTM7950 series desirable for high performance integrated circuit devices.
- PTM7950, based on a novel polymer PCM system, exhibits excellent interface wetability during typical operating temperature ranges, resulting in extremely low surface contact resistance.
- Package include: 1x Thermal Pad 40x80x0.25mm, 1x Phillips Screwdriver, 1x Cleaning Wipe, 1x Spatula, Finger gloves, 1x Cleaning Brush
